CHANDELIERS
CH70
Multi-Layer Trellis
DESIGNED BY PAUL RUDOLPH
Diffuse light chandelier—with a “linear” quality
Size & Proportion and drop are adjustable—and can be almost any dimension
Remote Transformer is necessary
Dimmable
SIZES
Overall size of Layers:
Lowest Layer: can be customized in various sizes.
Secondary layers: they’re generally smaller (so the secondary layers look like they “step in”)
Length & Width:
Lowest layer (generally the largest one): sides of the overall rectangle or square (that the fixture would fit into).
Upper layers: Modulightor can lay this out for you (or you can suggest a preferred design)
Drop:
Minimum: approximately 6” to bottom of top layer
Custom Drop: please specify in units-of-an-inch
LIGHT SOURCES
JC Xenon lamps (two lamps needed for each arm)
Base: Bi-Pin, G4
12 Volts
5 or 10 Watts (each lamp)
Remote Transformer necessary.
NOTE: Fixtures are provided with a set of lamps (or, if specified or integral to the fixture’s design, with LED’s), as specified by the customer. It is the customer’s responsibility to verify that their selection is compatible with their wiring, power, switching, and dimming system.
MOUNTING METHODS
MM01C (suspended by rods, and hardwired at 4-1/2" x 4-1/2" square plate, with "Modern Cap" screw visible at center of the plate)
DRAWINGS AND FILES
