Stella II CH130 Chandelier
RADIAL CHANDELIER
Available with 6”, 10”, and 16” arms
No transformer or driver necessary
Dimmable
SIZES
Length & Width: Sides of the rectangle or square can be of almost any length—please specify in units-of-an-inch (minimum length of a side is 17”)
Note: lengths over 12 feet will require a discrete seam
Drop (the distance FROM face-of-ceiling TO bottom-of-fixture):
Standard Drops: are approximately 12” or- approximately 18”
Custom Drops: are available with an up-charge
Minimum and Maximum Drops: If a drop is too short, one will see “hot spots” on the ceiling—and 11” is the approximate minimum drop to avoid that. BUT: if the drop is too large, the distance might cause an insufficient amount of light to bounce off the ceiling. When an average good drop is wanted, then approximately 18” seems to be best, and that can be extended to about 24” (Though designers sometimes specify drops which are larger than that.)
Adjustable Drops: Some mounting methods allow for field adjustment of the size of the drop, like the methods where the fixture is held-up by Cables (which can be field-trimmed), or when we provide Custom Drops (whose components allow for field-trimming).
LIGHT SOURCES
Available with various light bulbs.
NOTE: Fixtures are provided with a set of lamps (or, if specified or integral to the fixture’s design, with LED’s), as specified by the customer. It is the customer’s responsibility to verify that their selection is compatible with their wiring, power, switching, and dimming system.
MOUNTING METHODS
MM01B (suspended by stems, and hardwired through a stem—with No screws visible) – the most typically specified mounting
DRAWINGS AND FILES
